Harvest machinery
4QZ-M30(G4)
-
240HPPower
-
2.2/2.4MHarvest width
-
98%Grain breakage rate
-
30T/HWorking efficiency
Silage harvesting and baling machine, equipped with 2.2/2.4 meter disc cutting header. Equipped with a 240-horsepower engine, enabling dynamic power. Chain roller bar type baling mechanism, ensuring the compactness of the silage. Available for all land types except for mountainous areas.
Product features
-
1
Wheeled chassis for quick transfer, 4WD optional
-
2
Automatic quantitative and timed lubrication of the entire vehicle
-
3
Three models of cutting headers available
Shrub header, knives header, corn header.
-
4
High-density baling technology
-
5
Grain breakage rate above 98%
Use scenarios
Technical parameters
| Model | Unit | 4QZ-M30(G4) |
| Structure style | / | Wheel type |
| Overall dimensions (L×W×H) - Transportation status | mm | 7000×2300×3400 |
| Overall dimensions (L×W×H) - Working dimensions | mm | 7435×2350×3715 |
| Entire machine mass | kg | 7500 |
| Minimum ground clearance | mm | 340 |
| Operating speed | km/h | 1~6 |
| Working width | mm | 2000/2200 |
| Type of cutting header | / | Disc cutting header, with straight cut option, pick-up table |
| Type of cutter | / | Disc cutter |
| Type of feeding mechanism | / | Feeding roller |
| Type of straw chopping mechanism | / | Drum type |
| Type of grain crushing mechanism | / | Double roller type |
| Type of baling mechanism | / | Roller type |
| Silage bale width | mm | 850 |
| Silage bale diameter | mm | 1000 |
| Silage bale weight | kg | 500 |
| Travel and transmission - Drive gearbox type | / | High and low gearbox + hydraulic drive |
| Travel and transmission - Wheelbase | mm | 2830 |
| Travel and transmission - Wheel track - Guide wheel | mm | 1700 |
| Travel and transmission - Wheel track - Drive wheel | mm | 1670 |
| Travel and transmission - Tire specification and model - Guide wheel | / | 10.0/75-15.3 |
| Travel and transmission - Tire specification and model - Drive wheel | / | 15.0-24 |
